High Efficiency Busbar Cutting Machine / Hydraulic Cutting Tool For Metal Sheet

High Efficiency Busbar Cutting Machine / Hydraulic Cutting Tool For Metal Sheet
High Efficiency Busbar Cutting Machine / Hydraulic Cutting Tool For Metal Sheet High Efficiency Busbar Cutting Machine / Hydraulic Cutting Tool For Metal Sheet

Large Image :  High Efficiency Busbar Cutting Machine / Hydraulic Cutting Tool For Metal Sheet

Product Details:
Place of Origin: NINGBO CHINA
Brand Name: Linkai
Certification: ISO
Model Number: CWC
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: get the latest
Packaging Details: wooden case
Delivery Time: 2-4work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 200sets/day
Detailed Product Description
Model: 06242A-1A Packing: Wooden Case
Cutting Force: 300kn Cutting Range: Al/Cu 10*150mm,12*200mm
Name: Hydraulic Cutting Tools
High Light:

hydraulic crimping tool for electrical cables

,

hydraulic wire crimping tool

Busbar Punching Machine Hydraulic Bus Bar Cutting Tools For Metal Sheet Cutting 12mm



CWC Hydraulic Copper and Aluminum Busbar Cutter for 12mm 200mm Cu/ Al Plate

Hydraulic Copper Aluminum Bus-bar Cutter

Item number

06242-1 06242-1A
Model CWC-150 CWC-200



Cutting force

200KN 300KN

Max thickness

of sheet

CU/AL plate 10mm 12mm

Width of sheet

CU/AL plate 150mm

200mm

Height

approx.440mm approx.460mm

(KG)

Weight

approx.N.W30KG

G.W33KG

approx.N.W37KG

G.W40KG

Package

wooden case wooden case

Configuration: It is used to cut off the copper and aluminum platoon,and thehydraulic pump needs to be matched.

Busbar Punching Machine Hydraulic Bus Bar Cutting Tools For Metal Sheet Cutting 12mm

Application

Portable Model CWC Hydraulic Bus Bar Cutter For Cutting is formed by high strength alloy steel precision.It is high efficacy due to smooth fracture surface and neat without burrs. It only takes a few seconds to cut off the Angle. It is mainly used in the iron tower factory, cutting off in transmission and distribution engineering construction site.

High Efficiency Busbar Cutting Machine / Hydraulic Cutting Tool For Metal Sheet 0

High Efficiency Busbar Cutting Machine / Hydraulic Cutting Tool For Metal Sheet 1
