High Tensile Connector Shackle / Galvanized Steel Shackles For Connect Steel Wire

High Tensile Connector Shackle / Galvanized Steel Shackles For Connect Steel Wire
High Tensile Connector Shackle / Galvanized Steel Shackles For Connect Steel Wire High Tensile Connector Shackle / Galvanized Steel Shackles For Connect Steel Wire High Tensile Connector Shackle / Galvanized Steel Shackles For Connect Steel Wire

Large Image :  High Tensile Connector Shackle / Galvanized Steel Shackles For Connect Steel Wire

Product Details:
Place of Origin: NINGBO CHINA
Brand Name: Linkai
Certification: ISO CE
Model Number: GXK
Payment & Shipping Terms:
Minimum Order Quantity: 10SETS
Price: GET THE LATEST
Packaging Details: WOODEN CASE
Delivery Time: 5-8WORK DAYS
Payment Terms: T/T, L/C, Western Union
Supply Ability: 10000SETS/WEEK
Detailed Product Description
MODEL: GXK ITEM NO: 17131
RATED LOAD: 10~300KN APPROVED: ISO CE
WEIGHT: 0.15KG USE: CONNECTING TEEL ROPE
High Light:

transmission line tool

,

transmission tools and equipment

High Tensile Connector Shackle , Galvanized Steel Shackle For Connect Steel Wire



Highly Tensile Galvanized Steel Shackle,Screw pin anchor shackles meet the requirement of Federal Specification RR-C-271D type IVA, Grade A, Class 2.
Highly Tensile Galvanized Steel Shackle
Parameter :
Order
number
Model Mainsize (mm)
Rated
load(kN)
Weight
(kg)
A B C D
17131 GXK-1 55 42 12 20 10 0.15
17132 GXK-2 67 58 16 24 20 1.29
17133 GXK-3 97 82 20 34 30 0.8
17133A GXK-3A 97 112 20 34 30 0.9
17134 GXK-5 107 89 22 38 50 1.12
17134A GXK-5A 107 131 22 38 50 1.29
17135 GXK-8 128 97 30 45 80 2.4
17136 GXK-10 141 114 34 48 100 3.56
17137 GXK-16 152.5 139 37 54 160 4.8
17138 GXK-20 164 140 39 60 200 5.17
17139 GXK-30 186 146 50 68 300 7.5
High Strength Shackle, high strength connect shackle is used for connecting steel rope with loading operation.
Shipment
1. The tools will be shipped in container
2. We will ship the products within one month normally after receiving the payment.
3. Stock is available for standard product.
