Double Drum JJM5SQ Cable Winch Puller Winch Pulling Rope With 5T Load Capacity

Certification
China Ningbo Lingkai Electric Power Equipment Co., Ltd. certification
China Ningbo Lingkai Electric Power Equipment Co., Ltd. certification
I would like to tell you that I have already begun to distribute the catalog on the Vietnam companies to transfer electricity and all the companies

—— Mr. Guillermo

Thanks for your support, open our Kenya market larger and better.

—— Mr. John

The Tools for underground cable pulling project works very well.I am going to introduce to other companies in local.

—— Mr. Ara Minasian

I'm Online Chat Now

Double Drum JJM5SQ Cable Winch Puller Winch Pulling Rope With 5T Load Capacity

Double Drum JJM5SQ Cable Winch Puller Winch Pulling Rope With 5T Load Capacity
Double Drum JJM5SQ Cable Winch Puller Winch Pulling Rope With 5T Load Capacity Double Drum JJM5SQ Cable Winch Puller Winch Pulling Rope With 5T Load Capacity

Large Image :  Double Drum JJM5SQ Cable Winch Puller Winch Pulling Rope With 5T Load Capacity

Product Details:
Place of Origin: NINGBO CHINA
Brand Name: Linkai
Certification: ISO CE
Model Number: JJM5SQ
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Wooden case
Delivery Time: 10-15 work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 100 sets / month
Detailed Product Description
Model: JMM5SQ Name: Gasoline Cable Winch
Engine: Honda Feature: Double Drum
Rated Load: 5T Using: Pulling Rope
High Light:

portable capstan winch

,

gas powered winch

Double Drum Honda Gasoline Cable Winch Puller Winch With 5T Load Capacity



Double Drum Honda Gasoline Cable Winch Puller Winch With 5T Load Capacity:

Quick Details

1. Model:JJM5SQ

2. Engine:Honda gasoline GX390

3. Weight:290kg

4. Lead TimeL10 days after deposite

5. Payment:TT,LC

Double Drum JJM5SQ Cable Winch Puller Winch Pulling Rope With 5T Load Capacity 0

Technical Data Double Drum Honda Gasoline Cable Winch Puller Winch With 5T Load Capacity

Model Type Overall Size(mm) Weight(kg) Power Gear Pulling Force(KN) Pulling Speed(m/min)
JJM-5SQ 1330*800*600 290 GX390,13HP Gasoline Engine Slow I 50 6
SLOW II 30 10
Quick I 13 23
Quick II 10 30
Reverse/slow No Lifting 5
Reverse/quick No Lifting 17

Double Drum JJM5SQ Cable Winch Puller Winch Pulling Rope With 5T Load Capacity 1

Application

1. It is used for tower erection,pole setting,stringing wire in electrical power line construction.

2. Winch can be modified as per requirement, such as changing curve capstan

into straight even cylindrical shape and coming with steel rope.

3. Extensively applied to an under construction set of electric power, post and tele wire ways to tower group sets up

the pole.Apply to use in the wild non-transformer station, it will be convenient and agility.

5tons double capstan drum winch with trailer can match Honda/Yamaha gasoline engine, diesel or electric engine is extensively applied to an under construction set of electric power, post and tele wire ways to tower group sets up the pole.Apply to use in the wild non-transformer station, it will be convenient and agility.

Double Drum JJM5SQ Cable Winch Puller Winch Pulling Rope With 5T Load Capacity 2

Our Service:

High quality fasteners products with best price;
Many years excellent experience with pre-sale and after-sale service;
Strict quality control according to your requirement;
Professional packing team keep every pack safely;

Send you some free samples along with your cargo to share us quality;
