220V 700bar Hydraulic Crimping Tool Electric With Puncher / Bender / Cylinder

220V 700bar Hydraulic Crimping Tool Electric With Puncher / Bender / Cylinder
220V 700bar Hydraulic Crimping Tool Electric With Puncher / Bender / Cylinder 220V 700bar Hydraulic Crimping Tool Electric With Puncher / Bender / Cylinder

Large Image :  220V 700bar Hydraulic Crimping Tool Electric With Puncher / Bender / Cylinder

Product Details:
Place of Origin: NINGBO CHINA
Brand Name: Linkai
Certification: ISO CE
Model Number: JYB700
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Carton or Wooden
Delivery Time: 8-10 work day
Payment Terms: T/T, L/C, Western Union
Supply Ability: 200 sets / week
Detailed Product Description
Model: JYB700 Name: Hydraulic Pump
Engine: Electric Driven High Pressure: 70 Mpa
Low: 7 Mpa Power: 750 W
High Light:

hydraulic crimping tool for electrical cables

,

hydraulic wire crimping tool

220V 700bar Electric Hydraulic Pump With Hydraulic Puncher,Bender,Cylinder



It is a single-acting,double speed pump.It is used to provide pressurized oil to compatible tools: Cylinder, Crimping Head, Cutting Head, Busbar punching bending cutting tools, pipe bender etc. where 700 Bar (1000PSI) working pressure is required. Ram advancement and retraction are controlled by solenoid valve equipped inside.

Data Sheet 220V 700bar Electric Hydraulic Pump With Hydraulic Puncher,Bender,Cylinder

Rated Output 750W
Motor Voltage 220V/380V
Rated Pressure High 70Mpa,Low 7Mpa
Capacity

low pressure 5L/min

high pressure 0.9L/min

Oil reservoil capacity 7L
Frequency 50HZ
Size 35*27*51
Note double valve with pedal switch and hand switch

Portable Power Pack Electric Hydraulic Pump 10000 psi, 700bar

Use and Characteristics

Double speed high performance pumps, built in 10000Psi pressure overflow valve, can ensure the maximum flow when maximum pressure.Standard of can see an oil window, observe the location of oil, with the normal operation that assures machine;Equipped with low noise pure aluminum alloy enclosure motor and light weight, convenient to move.Can choose to equip long range wire to control a switch, easy to long-distance to leave an operate.Use the following Suggestions 200 T of hydraulic cylinder.

More Information 220V 700bar Electric Hydraulic Pump With Hydraulic Puncher,Bender,Cylinder

High pressure 70Mpa High pressure oil flow 0.9L/min
Low pressure 7 Mpa Low pressure oil flow 5.0L/min
Power 750W Voltage 220V~380V
Frequency 50Hz Rotation Rate 1400r/min
Oil tank 7L Oil 15#~46#Hydraulic oil

220V 700bar Hydraulic Crimping Tool Electric With Puncher / Bender / Cylinder 0

Our Service:

High quality fasteners products with best price;
Many years excellent experience with pre-sale and after-sale service;
Strict quality control according to your requirement;
Professional packing team keep every pack safely;

Send you some free samples along with your cargo to share us quality;

About us: Lingsheng Tools, which located in the southeast China, it is the earliest origin Power Tools Leading City in China. We are making the various related cable pulling tools, and hydraulic tension and puller to support the transmission work. Our Tubular Gin Pole, Come Along Clamp, Wire Rope Pulley Block, Nylon Sheave Hoisting Tackle, Cable Mesh Sock Grip, Line Stringing Swivel…all are OEM and professionally produced per ISO 9001:2008, they are being sold to over more than 50 countries in the world, and has wined the best brand reputations. Some items like the Cable Drum Trailer, and the cable jack stands we can customized, and the Construction Safety Tools ,are not demanded the MOQ. You can freely help you out either Technical questions or Products requirements. Please approach us.
